Broadway Limited 8383 2-8-0 Consolidation, GN 1145, Paragon4 Sound/DC/DCC, w/ Smoke, N

In the late 1800's, the 2-8-0 Consolidation quickly became a staple on railroads worldwide, offering a highly efficient alternative to the 2-6-0 Mogul.  The Consolidations were capable of hauling trains twice as heavy at a fraction of the cost - - they revolutionized freight transportation.

Initially, only a few railroads adopted the design when Baldwin first introduced it. However, its reputation soared when the Pennsylvania Railroad made it their primary freight locomotive in 1875.  In total, over 33,000 Consolidations were built in the U.S., with 12,000 exported and 21,000 serving domestically.  The 2-8-0 wheel arrangement was also used in Australia, Canada, Finland, New Zealand, South Africa and many other countries around the world.

Today many Consolidations are preserved with a few still operating in excursion service. One of the most notable is the Southern Railway Ks-1 class No. 722, which was run in excursion service until 1985, and is now being restored by the Great Smoky Mountain Railroad.

Our first production run of these newly tooled Consolidation locomotives includes eight different railroad versions, plus one unlettered model for those who want to customize their own railroad.  Models with the Paragon4 Sound/DC/DCC decoder feature working smoke, while models with Stealth boards are DCC-Ready and come with an 8-ohm speaker already installed.  Next18-compatible decoders can be easily added to these boards for even more control and features.

Industry-leading Model Features:

• Paragon4 Sound & Control System featuring ROLLING THUNDER
• Integral Dual-Mode Decoder with Back EMF for Superb Slow Speed Operation in DC and DCC
• Precision Drive Mechanism Engineered for Heavy Towing and Smooth Slow Speed Operation
• Operating Smoke Unit with On/Off Switch - Note that N scale smoke units require a thin-viscosity smoke fluid such as JT's Mega Steam or Marklin's #02421
• Three Drivers and All Tender Wheels Pick-up Electricity from Track
• Die Cast Locomotive Body with Die Cast Chassis for Heavier Weight and Maximum Tractive Effort
• Equipped with Rubber Traction Tires for Additional Tractive Effort
• Premium Caliber Painting
• Prototypically Accurate Paint Schemes and Road Numbers
• Many Separately Applied Details such as Handrails, Grab Irons, Piping, Tender Ladders, Whistle, and Bell
• Prototypical Headlight and Rear Light Operation

• Prototypical Sounds of an early USRA steam locomotive, with several alternative whistles
• Operating Microtrains-compatible Couplers

• Will Operate on Code 55, Code 70, and Code 80 Rail
• Minimum Operating Radius: 9.75 inches


Introduction to Paragon4 Series Sound:

Broadway Limited Imports is proud to introduce Paragon4: The new benchmark for premium sound-equipped locomotives. These DC and DCC-Sound equipped locomotives feature the ALL-NEW Paragon4 sound and control system. Each Paragon4 locomotive comes with BLI's own integral DCC Decoder factory installed. Paragon4 locomotives offer Dual Mode DC and DCC operation with superb back EMF motor control, improved DC motor control, additional built-in capacity for more reliable electrical pick-up, industry best on-board sound with Rolling Thunder functionality, Pro Lighting Mode for prototypical light control, optional Switcher Mode for precise low speed control, and recordable DCC operation for automated playback.

Paragon4 Sound & Control SystemFeatures:

• Operates in DC & DCC with improved DC speed control (use DCMaster for DC Sound)
• Built-In additional capacity to navigate imperfect track

• Pro Lighting Mode offers individual control of all lights on model
• Switcher Mode for precise low speed control.
• Record & Play Operation - Records and plays back sounds and movements once or repeatedly for automatic operation
• High Resolution Audio
• Quillable Whistle for various whistle lengths and patterns
• Choice of 3 selectable Whistles
• Alternate Whistle / Horn where applicable for locomotive with air horn and steam whistle - both the main whistle and alternate can be easily played
• Adjustable bell ringing interval for faster or slower bell
• Numerous user-mappable functions with available keys
• Johnson Bar Sound at Direction Change
• Multiple realistic passenger and crew sounds play on command
• Grade Crossing Automatic Signal
• Automatic Forward / Reverse Signal - When activated, stopping triggers and stop whistle toot. When moving forward from a stopped position, toots twice. When moving in reverse. toots three times.
• Chuff sound intensity varies with load
• Individually adjustable sound volumes for each effect
• EZ Reset Button for quick return to factory default settings

**Specifications on this page subject to change.
